A lift panel has a harder job than most industrial panels: it carries people, it must obey a safety chain that cannot be argued with, and its ride quality is judged by every passenger every day. We build elevator control panels in Faridabad with VVVF drives, proper call logic and ARD rescue — wired and tested before they leave.
A lift control panel — elevator controller — takes calls from landings and from inside the car, decides the order to serve them, drives the motor through acceleration and deceleration, levels the car at the floor, and opens the doors. Underneath all of that sits a safety chain that must be able to stop the lift regardless of what the logic thinks.
That last point is what separates lift panels from every other industrial panel we build. Elsewhere, a fault means a stopped machine. Here it means people in a box between floors. So the safety chain is hard-wired in series through every device — governor, overspeed, final limits, pit and car top stops, door contacts, safety gear — and the drive cannot energise if any one of them opens. No software decides that.
Ride quality is a control problem, not a mechanical one. Passengers do not know what a VVVF drive is, but they know a lift that jerks on start and lands with a bump, and they judge the whole building by it.
Passenger lifts in residential and commercial buildings, hospital and stretcher lifts, goods and freight lifts, dumbwaiters and service lifts, and industrial platform lifts. We build panels for new installations and as replacements where an existing controller has become obsolete and unsupportable — the lift equivalent of the CNC retrofits we do for machine tools.
In a building, the lift panel usually sits alongside a fire fighting panel whose signal it must obey, an LT distribution board, and often a car parking control panel in the basement.
Designed, wired, ferruled and tested in our own Faridabad workshop, and supplied with the GA drawing and wiring schematic.
In series through every safety device, independent of the logic. The drive cannot energise if any contact opens — no software involved.
Programmed acceleration, travel, deceleration and levelling. Passengers notice smoothness even if they cannot name it.
Battery-backed move to the nearest floor and doors open. Not an optional extra in our book.
Encoder or shaft sensing so the car stops flush with the floor regardless of load — the commonest complaint on cheap controllers.
Recall to the designated floor on a fire signal, then fireman control, wired to the fire alarm panel.
Collective logic that serves calls in a sensible order, so two lifts in a lobby do not both answer the same call.
Photographs from our Faridabad workshop and from customer installations.
lift-control-panel.jpgComplete lift panellift-panel-internal.jpgInternal wiring and ferrulinglift-panel-vvvf.jpgVVVF drive mountedlift-panel-ard.jpgARD battery unitlift-panel-schematic.jpgWiring schematic suppliedlift-panel-installed.jpgPanel in machine roomLift panels are built to the lift design, not to a catalogue. Everything below is confirmed in writing before manufacturing.
| Parameter | What it covers | Fixed at |
|---|---|---|
| Lift type | Passenger, goods, hospital, dumbwaiter or platform | Enquiry |
| Capacity and speed | Rated load, rated speed and travel height | Enquiry |
| Number of stops | Floors served, and openings per floor | Enquiry |
| Drive | VVVF make and rating, geared or gearless machine | Drawing approval |
| Control type | Simplex, duplex or group, collective operation | Drawing approval |
| Door operator | Make, type, timing and reopening arrangement | Drawing approval |
| ARD | Battery capacity and rescue sequence | GA approval |
| Safety devices | Every device in the chain, listed and wired in series | GA approval |
| Interfaces | Fire alarm, BMS, indicators, announcements | GA approval |
Many lifts in Delhi NCR are mechanically sound but running on controllers nobody supports any more — relay logic, or an early drive whose spares no longer exist. Replacing the controller and drive while keeping the machine, ropes and guides restores ride quality and reliability for far less than a full modernisation.
We survey the installation first, list what is reusable and what is not, and give you a written scope. Where the machine or the safety gear is beyond its life, we say so — a modern controller on unsafe mechanics is not something we will build.
Because a lift carries people. A hard-wired series chain through every safety device means the drive cannot energise if any contact opens, regardless of what the logic believes or whether the processor is healthy. Software supervises the lift; it does not decide whether it is safe.
An automatic rescue device moves the car to the nearest floor on battery after a power failure and opens the doors. Given how power behaves in most of India, we treat it as standard rather than optional.
Levelling. It usually means position feedback or the levelling parameters are not compensating for load and rope stretch. A properly set VVVF controller with encoder feedback lands flush whether the car is empty or full.
Yes, where the machine, ropes, guides and safety gear are sound. We survey first and give you a written scope of what is reusable. If the mechanics are past their life we will tell you rather than fit a new controller onto them.
Yes — simplex, duplex and group control with collective operation, so lifts in a lobby share calls sensibly instead of both answering the same one.
Yes. Fireman\u2019s recall to the designated floor on a fire signal is wired from the fire alarm panel, along with fireman control operation.
Yes — Delhi NCR, Gurugram, Manesar, Bhiwadi, Ghaziabad, Noida and across India.
Share the drawing or a photo on WhatsApp and we will come back with a method, a cycle time and a price.
